Designing an MCP Server for Real Traffic

The problem

The Model Context Protocol gives an AI host — Claude Desktop, an IDE, a custom agent — a standard way to talk to external tools and data. Every getting-started guide shows you the same thing: a single server process, a stdio pipe, one client, one conversation. That version takes about twenty minutes to build, and it teaches you nothing about what happens the moment a second user shows up.

The real question isn't "how do I expose a tool to an LLM." It's:

• What happens when a user closes their laptop mid-conversation and comes back tomorrow — does the server remember them?
• What happens when 25 people hit the server in the same second?
• What happens when the process restarts — does every open conversation just vanish?
• Who's allowed to call this tool at all, and how do they prove it?
• If one server isn't enough, how do you run three of them without them stepping on each other?

None of this is exotic. It's the same list any backend service has to answer. MCP doesn't get a pass just because the client happens to be a language model instead of a browser. This article walks through a server we built — in TypeScript, layer by layer — that answers all five questions, and more usefully, the mistakes we made building it, because the mistakes are where the actual design constraints reveal themselves.

The shape of the system

At a high level, there are four concerns, and the entire project is really about keeping them separate:

1. The MCP protocol layer — tool registration, the JSON-RPC handshake, the transport. This is what talks to the client.
2. Application state — the actual conversation: who said what, in what order, tied to a session_id.
3. Identity — who is allowed to call the tool, enforced via OAuth 2.1.
4. Distribution — running more than one instance of this thing, and a load balancer deciding where a request goes.

The single most important design decision in the whole system is this: the process running the MCP server should not be where your data lives. Everything that needs to survive a restart, a redeploy, or a scale-out event has to live somewhere else. The server process becomes disposable. That one sentence is the reason every file in this project exists.

Layer 1: separating "hot" state from "durable" state

A conversation has two different lifetimes. The last few turns need to be read on every single request — that has to be fast. The full history needs to survive forever — that has to be durable. Trying to serve both needs from one store is how you end up with either a slow cache or a lossy database.

So there are two stores, deliberately kept behind identical interfaces:

// session-store.ts — stands in for Redis
export class SessionStore {
  async get(sessionId: string): Promise<SessionState | null>
  async create(sessionId: string): Promise<SessionState>
  async update(sessionId: string, patch: Partial<SessionState>): Promise<void>
}

// history-store.ts — stands in for Postgres
export class HistoryStore {
  async append(sessionId, role, content, idempotencyKey): Promise<Turn | null>
  async getHistory(sessionId: string, limit?: number): Promise<Turn[]>
  async countTurns(sessionId: string): Promise<number>
}

In the demo both are backed by an in-memory Map. That's intentional, not lazy — the entire point is that the method signatures are what the rest of the system depends on, not the storage engine behind them. Swap the internals for ioredis and pg later and nothing that calls these two classes needs to change. This is the same reasoning behind a repository pattern in any backend codebase; MCP doesn't change the argument.

Two details in HistoryStore matter more than they look:

• Idempotency keys. Every append() call takes one. At scale, retries happen — a client times out and resends a request that actually succeeded server-side. Without an idempotency guard, that retry writes the same turn twice, and now your conversation history is corrupted. The guard makes a retried write a safe no-op instead of a duplicate.
• A running summary field on SessionState. Once a conversation passes a turn threshold, older turns collapse into a summary instead of being replayed verbatim on every call. This is the same reason long support tickets get summarized before a new agent picks them up — replaying the entire raw transcript into context on every turn gets expensive and eventually exceeds what the model can usefully attend to.

Layer 2: the tool itself, and two sessions that look like one

The MCP server exposes a single tool, chat, and its logic is a five-step resolve-append-generate-append-update cycle:

async ({ session_id, message, idempotency_key }) => {
  // 1. Resolve session — cache first, rebuild from durable history on a miss
  let session = session_id ? await sessionStore.get(session_id) : null;
  if (!session_id) {
    session_id = `sess_${randomId()}`;
    session = await sessionStore.create(session_id);
  } else if (!session) {
    // Cache miss: instance restarted, TTL expired, or a different
    // instance created this session. Rebuild from the durable store.
    const priorTurns = await historyStore.getHistory(session_id);
    session = await sessionStore.create(session_id);
    await sessionStore.update(session_id, { turnCount: priorTurns.length });
  }

  // 2. Durably persist the user's turn
  await historyStore.append(session_id, "user", message, idempotency_key);

  // 3. Load recent context
  const recentTurns = await historyStore.getHistory(session_id, 20);

  // 4. Generate a reply (a real model call, in production)
  const reply = generateReply(session, recentTurns, message);
  await historyStore.append(session_id, "assistant", reply, `${idempotency_key}-reply`);

  // 5. Update session state, summarizing if history has gotten long
  await sessionStore.update(session_id, { turnCount, runningSummary });

  return { content: [{ type: "text", text: JSON.stringify({ session_id, reply }) }] };
}

Step 1's else if (!session) branch is the whole reason HistoryStore exists as a separate thing from SessionStore rather than one combined store. A cache miss on a valid session isn't an error — it's expected the moment you have more than one server instance. The durable store is what lets the next instance pick up a conversation the first instance started.

Here's the part that isn't obvious until you actually build the transport layer: there are two completely different things both called "session," and conflating them is the single easiest mistake to make in this whole system.

We found this the hard way. The first version of the server created a brand new transport object per HTTP request, reasoning that "stateless is good, so let's make everything stateless." That broke the very first test:

StreamableHTTPError: Bad Request: Server not initialized

The MCP protocol's initialize handshake and the requests that follow it have to hit the same transport object — that's protocol-level session bookkeeping, not application data, and it's not optional. The fix was a Map<protocolSessionId, transport> kept alive in the server process, alongside — and clearly separated from — the externalized conversation state. Losing that map on a restart just means open connections have to reconnect. It never touches the conversation itself, because the conversation was never stored there.

Layer 3: proving who's calling

A tool that holds conversation history for anonymous callers isn't a real system, it's a demo. Real traffic needs identity, and MCP's answer is OAuth 2.1 with PKCE and dynamic client registration — the same mechanism a mobile app uses to get access to your calendar, applied to an AI client getting access to a tool server.

The flow has two very different frequencies, and getting them backwards is the second bug we hit:

Registration is an app-level event — it happens once, when the client software is first configured. Authorization is a per-user event — it happens at login. Our first draft of the traffic simulator got this wrong: it registered a brand-new OAuth client for every simulated user, as if every single login were also a fresh app install. Twenty-five simulated users in a burst test meant twenty-five registrations in a few hundred milliseconds, which tripped the authorization server's own rate limiter (20 registrations/hour by default — a real, deliberate anti-abuse control). The fix wasn't to raise the limit. It was to fix the simulation: register the client once, then run 25 independent authorize→token exchanges against that one client_id, which is what actually happens when 25 people log into the same app.

The server side implements the standard OAuthServerProvider interface — authorize, challengeForAuthorizationCode, exchangeAuthorizationCode, exchangeRefreshToken, verifyAccessToken, revokeToken — all of it backed by in-memory maps for the demo, all of it following the same swap-later principle as the session/history stores. The one piece that's a deliberate, clearly-commented shortcut: authorize() auto-approves as a single demo user instead of rendering a real login screen. That's the one thing standing between this and a production authorization server — everything else, including PKCE verification and token expiry, is the real protocol.

Layer 4: more than one server, and the bug that explains the whole architecture

Everything above works on one instance. The moment you put a load balancer in front of three instances, a new failure mode appears that doesn't exist with one: a token minted by instance A doesn't mean anything to instance B.

We built the load balancer with what seemed like a reasonable routing strategy: hash the bearer token to pick a backend, so requests from the same authenticated user consistently land on the same instance. It compiled, it looked correct, and it failed on the very first real request:

{"error":"invalid_token","error_description":"Invalid access token"}

The bug: the OAuth handshake (/register, /authorize, /token) happens before a client has a token, so those requests were routed by client IP. The subsequent authenticated /mcp calls were routed by a hash of the token itself. Different routing key, same client, possibly different backend — and a token minted on instance A means nothing to instance B, because the token store is still an in-memory Map per process, exactly like the session store. The fix was to route everything — the handshake and the authenticated calls alike — by the same key (client IP), so one client's entire lifecycle consistently lands on one instance.

That fix is correct and it's also, deliberately, a temporary patch, and the load balancer's source says so directly:

/**
 * A naive round-robin balancer would break both: a token minted by
 * instance A won't verify on instance B, and an MCP protocol session
 * opened on A won't be found on B. So THIS load balancer sticks every
 * client (by IP) to one backend for its whole lifecycle, as a stand-in
 * for real horizontal scaling. Once Redis + Postgres are wired in for
 * app state, and OAuth tokens are likewise moved to a shared store, you
 * can delete the stickiness and go pure round-robin — that's the whole
 * point of externalizing state.
 */

This is the cleanest possible demonstration of the thesis from the top of this article. The load balancer needs sticky routing specifically because two pieces of state — OAuth tokens and the MCP protocol session map — still live inside the process instead of in a shared store. The moment those move to Redis, the stickiness requirement doesn't get worked around, it gets deleted, because the reason for it stops existing.

How this maps to a real scenario

Picture a support chatbot embedded in a SaaS product. A customer opens the widget, asks a question, gets an answer, closes the tab. Two days later they reopen the same conversation from their phone. Meanwhile a thousand other customers are doing the same thing, at the same time, across a release that just autoscaled the backend from three pods to eight.

Every piece of this system maps directly onto that scenario:

• The customer's identity — OAuth token, obtained once at login, reused across every message in the widget session.
• "Reopen the same conversation from their phone" — the session_id round-trips through the client and is resolved against the durable history store, not tied to whichever pod happened to serve the first message.
• The release that autoscales three pods to eight — new pods coming online with zero conversation state of their own is fine, because conversation state was never pod-local. It's the exact cache-miss branch in the chat tool: rebuild session state from durable history the first time a new pod sees an existing session.
• A thousand customers at once — the load balancer spreading requests across the pool, backed by health checks so a pod that's struggling stops receiving new traffic.
• Idempotency keys — the thing that keeps a flaky mobile connection's automatic retry from duplicating a customer's message in the transcript their human agent reads later.

None of this is speculative extrapolation — it's the direct behavior of the code above, exercised with an actual MCP client, an actual OAuth flow, and an actual three-instance cluster behind an actual reverse proxy, not a diagram of intentions. A 25-request concurrent burst, one multi-turn conversation proving continuity across calls, one unauthenticated request correctly rejected, one forged token correctly rejected — all run and passing before any of this was written up.

What's still a stand-in, on purpose

Being direct about the remaining gaps matters more than pretending they don't exist:

1. Session and history stores are in-memory Maps, not Redis/Postgres. The interface is final; the backing implementation is a placeholder by design.
2. OAuth client/code/token storage is in-memory too, for the same reason — and it's the direct cause of the load balancer needing IP stickiness at all.
3. The authorize() step auto-approves instead of showing a real login screen. This is the one piece that's a genuine shortcut rather than a swappable implementation detail, and it's the first thing to replace before any of this sees real users.
4. The MCP protocol session map is inherently per-process — this one doesn't go away with a database swap. It's a property of the Streamable HTTP transport itself, and production deployments handle it either with sticky routing at the protocol layer or by having clients tolerate reconnect-per-request.

Each of these is named explicitly in the code as a comment at the point where it matters, rather than left as an implicit assumption — because the difference between "a stand-in we know about" and "a bug we haven't found yet" is entirely in whether it's written down next to the line of code responsible for it.
